High Quality Ceramic Fireproof Board 1200-1800c Alumina Ceramic Fiber Board For Thermal Insulation

Großes Bild : High Quality Ceramic Fireproof Board 1200-1800c Alumina Ceramic Fiber Board For Thermal Insulation

Produktdetails:

Herkunftsort:	Henan, China
Markenname:	RONGSHENG
Zertifizierung:	ISO9001

Kontakt

High Quality Ceramic Fireproof Board 1200-1800c Alumina Ceramic Fiber Board For Thermal Insulation

Beschreibung

Aussehen:	Weißes Pulver, Flüssigkeit/Weißes Pulver	Produktionsprozess:	Schießen bei hohen Temperaturen
Schlupfkapazität:	10.5	Physische Eigenschaften:	Hohe Dichte, geringe Porosität, hohe Festigkeit
Cao min:	33	Herkunft:	Xinmi
Rohstoff:	Kohlenwasserstoff	Zähne in Masse Min.:	2.4
Vorteil:	Niedriger Aschewiderstand	Feuchtigkeit:	In der Lage, Kraft bei hohen Temperaturen aufrechtzuerhalten
Qualitätsstandards:	Die internationalen Standards wie ISO, ASTM usw. einhalten.	Reinheit:	99%
Typ:	Aluminiumdihydrogenphosphat	Eincs Nr:	236-875-2
Schüttdichte:	0,5
Hervorheben:	fireproof ceramic insulation board , alumina ceramic fiber board , high temperature refractory board

Ceramic fiber board is a high-performance insulation product made of high-purity ceramic fiber by adding the right amount of organic matter and binder. It is flat, ceramic materials are evenly distributed, free of asbestos and environmental protection. ceramic fiber insulation boards solid texture, wind erosion resistance, excellent toughness and other advantages make it an ideal material for kilns, pipes and other insulation types of equipment. It has low thermal conductivity and low thermal storage, and no expansion during heating, which can reduce energy cost and cycle time, and protect the surface of refractory from thermal shock and chemical attack.

Product Advantage

Fire resistant ceramic fiber board advantage:


1, with high temperature thermal conductivity, light weight, long life, tensile strength, good elasticity, non-toxic and so on.

2, high compressive strength, long service life;

3, low heat capacity, low thermal conductivity;

4, non-brittle material, good toughness;

5, the size of accurate, good flatness;

6, easy to install,

7, excellent anti-wind erosion performance;

8, continuous production, fiber distribution, performance and stability;

9, excellent sound and noise reduction performance.

Specification

Type		COM	ST	HP	HA	Zir-Alu	HZ
Classified Temp.		1100ºC (1983ºF)	1260ºC (2300ºF)	1260ºC (2300ºF)	1360ºC (2480ºF)	1400ºC (2550ºF)	1430ºC (2600ºF)
Working Temp.		<1000ºC (2012ºF)	1050ºC (1922ºF)	1100ºC (2012ºF)	1200ºC (2192ºF)	1200ºC (1192ºF)	1350ºC (2462ºF)
Color		white	white	white	white	white	white
Density(kg/m3)		260-320 (16-20lb/ft3)	260-320 (16-20lb/ft3)	260-320 (16-20lb/ft3)	260-320 (16-20lb/ft3)	260-320 (16-20lb/ft3)	260-320 (16-20lb/ft3)
Linear Shrinkage (%) (24 hrs)		-3 (1000ºC/1832ºF)	-3 (1000ºC/1832ºF)	-3 (1100ºC/2012ºF)	-3 (1250ºC/2282ºF)	-3 (1000ºC/2012ºF)	-3 (1350ºC/2462ºF)
Thermal conductivity (W/M.K)		0.085 (400ºC/752ºF) 0.132 (800ºC/1472ºF) 0.180 (1000ºC/2012ºF)	0.085 (400ºC/752ºF) 0.132 (800ºC/1472ºF) 0.180 (1000ºC/2012ºF)	0.085 (400ºC/752ºF) 0.132 (800ºC/1472ºF) 0.180 (1000ºC/2012ºF)	0.085 (400ºC/752ºF) 0.132 (800ºC/1472ºF) 0.180 (1000ºC/2012ºF)	0.085 (400ºC/752ºF) 0.132 (800ºC/1472ºF) 0.180 (1000ºC/2012ºF)	0.085 (400ºC/752ºF) 0.132 (800ºC/1472ºF) 0.180 (1000ºC/2012ºF)
Compression Strength (Mpa)		0.5	0.5	0.5	0.5	0.5	0.5
Chemical(%)	Al2O3	44	46	47-49	52-55	45-46	39-40
	Al2O3+SiO2	96	97	99	99	-	-
	Al2O3+SiO2+ZrO2	-	-	-	-		99
	ZrO2	-	-	-	-	.5-7	15-17
	Fe2O3	<1.2	<1.0	0.2	0.2	0.2	0.2
	Na2O+K2O	≤0.5	≤0.5	0.2	0.2	0.2	0.2
Size(mm)		12001000mm(47″40″); 1000600mm(40″36″);900600mm(24″36″) 20-50mm(1″/2″)thickness

Product Application

Fire resistant ceramic fiber board applications:


1.Industrial kiln wall lining, masonry insulation layer, high temperature, high heat equipment insulation, insulation, high temperature kiln kiln lining, kiln car, door baffle, furnace furnace temperature divider, aerospace, shipbuilding insulation, Fireproof, soundproof, insulated. 2.Iron and steel industry: expansion joints, insulation, insulation and insulation; non-ferrous metal industry: backing insulation materials, tundish and tank cover for pouring copper and copper alloy; 3.Ceramic industry: light kiln car structure and the furnace hot surface lining, the furnace temperature zone separation and fire materials; Glass industry: the pool was lining heat, burner block; 4.Furnace building: hot surface refractories (alternative fiber blanket), heavy refractory lining, expansion joints; 5.Light industry: lining of industrial and domestic boiler combustors; 6.Petrochemical industry: high temperature heating furnace lining hot surface material; 7.Building materials industry: cement rotary kiln and other equipment insulation.
